Light Railway Commission Sheet No. 9
Light Railway Commission Sheet No. 9

From Light Railway Commission folder 'The Mound, Embo & Dornoch Light Railway' with 'Plans and Sections' of the proposed light railway from The Mound Station, on the Highland Railway, to Embo and Dornoch.

The sheet is a lithographed technical drawing showing a further and final section including the town of Dornoch. This plan is of broader interest showing the buildings of Dornoch in 1896. Scales are provided in lengths and heights of longitudinal cross-sections, as is the inclination. This section has the highest inclination on the approach to Dornoch.
Picture added on 19 June 2019 at 14:13
