Light Railway Commission Sheet No. 2

From Light Railway Commission folder 'The Mound, Embo & Dornoch Light Railway' with 'Plans and Sections' of the proposed light railway from The Mount Station, on the Highland Railway, to Embo and Dornoch.

The sheet is a lithographed technical drawing showing the crossing of the Mound including cross-sections and provided with scales in lengths and heights of longitudinal cross-sections. The inclination is also given.
Picture added on 19 June 2019 at 14:05
